Model STS Indoor Tempering System
PRESS THE RESET BUTTON BELOW TO RESET TO DEFAULTS
MODEL CODE BUILDER
Select from the options below
Location
Water Heater options
Tankless Option
Shower Eye/Face
Voltages
Classificatio
n
Booster Pump
Recirc Pump
STS
1-Indoor
2-Outdoor
-
0- No Tank
1-119G non ASME Tank
2-120G ASME Tank
3-200g ASME Tank
4-310G ASME Tank
-
0-None
1-77kw
2-115kw
3-154kw
-
0-none
1-included
-
1-480v 3phase
2-600v 3phase
3-other*(specify)
-
0-general Purpose
1-Nema 4
2-Nema 4X
3-CL1 DIV2
-
0-None
1-Required
-
0-None
1-Required
CONTACT INFORMATION
NAME:
COMPANY:
EMAIL:
PHONE:
